Lazzati HB 160MM Evo 4.0: Advanced Technology for Maximum Production Efficiency

19.06.2025

In the landscape of large-format machine tools, the demand for smart, precise, and high-performance solutions is constantly growing. LAZZATI S.p.A., a company with over 85 years of experience in the sector, has developed the HB 160MM Evo 4.0, a horizontal milling and boring machine designed to ensure maximum productivity and total control in the most complex machining operations.

Photo: CNC-PRO

Innovative Design for Optimal Performance

Designed with a modular architecture and a GJL250 cast iron structure, the HB 160MM Evo 4.0 ensures superior structural rigidity and vibration-free operation. The LHS - Lazzati Hydrostatic System guarantees smooth, frictionless movements, preserving precision over time and significantly reducing maintenance costs. The DCS - Dynamic Compensation System maintains volumetric accuracy below 0.015 mm, making the machine ideal for high-precision machining on large components. Additionally, the TCS Evo Boring system ensures constant thermal control of the boring spindle and structures, guaranteeing precision in every ambient condition.

Technology and Power for Maximum Output

The HB 160MM Evo 4.0 is equipped with a 160 mm diameter boring spindle, with 80 kW power and 4,000 Nm torque, capable of operating at speeds up to 4,000 RPM. Thanks to the DPS-X system with double pinion and backlash recovery and the LAS system for active stabilization of the axes, the machine achieves rigidity values never obtained before, significantly increasing tool life and surface finish quality. The A UA 360 automatic universal head allows positioning on two axes with 1° precision, increasing versatility for complex operations. With large axis travels (4,000 + n° x 1,000 mm in X, 3,000 ÷ 5,000 mm in Y, 1,600 mm in Z, and 1,100 mm in W), the machine is perfect for high-intensity sectors such as earthmoving, naval, and energy industries.

Automation and Digital Intelligence

Equipped with a Heidenhain iTNC640 CNC, the HB 160MM Evo 4.0 is a 4.0-ready machine, featuring advanced functionalities that enhance production management:

• RT3D – Real-Time 3D Head Management: real-time head positioning control for high-precision machining.
• LHI 5.0: an 18.5” touch interface that simplifies human-machine interaction.
• LED 5.0 & LRD - Lazzati Remote Diagnosis: real-time remote monitoring to minimize downtime and optimize maintenance.
• LES - Lazzati Energy Saving: up to 25% reduction in energy waste, thanks to an intelligent energy management system.

Maximum Operational Flexibility

To meet the most specific requirements, the HB 160MM Evo 4.0 is fully configurable with custom accessories, including:

• Automatic tool changers with up to 240 positions to reduce setup times.
• Hydrostatic rotary tables with maximum admitted load from 15 to 120 tons.
• Automatic universal head with 1°x1° or 0.001°x0.001° indexing.
• Pick-up station for automatic head change.
• Customizable floor plates supporting loads up to 15 tons/m².

A Customer-Centric Experience

The user interface is designed to maximize operational efficiency, making the HB 160MM Evo 4.0 accessible even to less experienced operators. The ergonomic platform offers easy access, optimal visibility, and intuitive controls, improving both productivity and safety.

Conclusion: The Future of Industrial Milling

The Lazzati HB 160MM Evo 4.0 is the result of continuous technological research and a relentless focus on customers’ production needs. With a combination of precision, power, and digital intelligence, this machine positions itself as the ideal choice for companies looking to optimize their production process and tackle the challenges of Industry 4.0 with cutting-edge solutions.

For more information contact the representive for Slovenia: CNC-PRO, d.o.o. > info@cnc-pro.si > +386 4 29 27 230. www.cnc-pro.si
